Advantaged Feature

 High Voltage Protection

 Independent input and output signal (include earth cable of signal)

 Separate signal amplifier system and individual LED light of each channel

 Wide input stable electric power supply: AC88 ~256V

 Light weight


Technical Parameter

 DMX512/1990 Standard

 Input/output: XLR Pin3 Optional:XLR Pin5

 Eight-way DMX distributor with one input

 Input Voltage: AC88~256V 50/60Hz

 Dimension: 19" 1U, 482mm×173mm×44mm

 Net Weight: 2.05 Kg

 Standard DMX512 signal; 2.4G wireless

 DMX512 receiver

 Communication distance:300m (visible distance)


TIPS:
When use two same position outputs at both front and rear panel at same time, this two outputs can be connected 32 lighting fixtures total.When use single side output at same position, this output can be connected with 32 lighting fixtures
maximum.


Up to CE standard, UL standard and GB7000.15-2000 standard
