1305-DMX-240B console

  • PID:1305
  • Wechat:13825163720; 18928719131
  • Phone: (8620)36399170
  • Tel: (8620)36399170
  • Email: info@showart.com.cn
  • FEEDBACK

Technical Parameter

* Each scene can store independent time and fade time
* Each step of Chase can store independent time and fade time
* Auto run while connect to electric

* 12 scanners of 16 channels each
* 30 banks have 8 programmable scenes each
* 6 programmable chases of 85 steps each
* 8 slider for manual control of channels
* Assignable joystick for ease of movement
* The data of console can be sent and received between 2 units via CANNON signal cable
* In fade mode, ALL (all channel) or X/Y only could be selected separately
* Fine adjustment for Wheel pan and TILT
* Midi control over banks, chases and blackout
* LED lamp connector
* Power input: DC 9-12V 1000mA
* Audio input: by built-in microphone or linein, 100mv-1vpp
* DMX in/out: 3 pin male/female XLR
* Dimension : 482mm × 190mm ×90mm
* Net Weight: 2.6KG


Up to CE standard, UL standard and GB7000.15-2000 standard
