Technical Parameter

* Auto save last running data when power off ordisconnect electric suddenly. Console will auto run continue while power ON or connect to electric

* Set X,Y to light joystick of single fixture

* Select one or multi chases to run in cycle

* DMX512/1990 Standard 228 channels

* LCD display with backlight

* Up to 12 scanners may be connected with a maximum of 16 channels each 24 Dimmer channels,12 channels for switch of lamp

* 8 slider for manual control of channels

* Assignable joystick for ease of movement

* Manual operate enable

* 12 chases (at most 40 steps for each chase)

* 480 chase steps

* Range of cross time: 0s-25.5s

* Range of speed time: 0.1s-25.5s

* Each chase speed and cross time can be saved automatic

* 512K high capacity memory card

* The Data auto-saves

* DMX signal output connector: XLR-D3F

* Power input: DC9V 1000mA

* Dimension: 485mm×250mm×91mm

* Net Weight: 3.8KG
