Technical Parameter

* DMX 512/1990 Standard, 512 DMX control channels

* 4 output with optical isolated , with stand 2000 Vrmms

* Up to 50 SHAPE generators. SHAPE track control is provided to control such effects as circles, lines and shapes like 8 etc

* Up to 32 scanners may be connected with a maximum of 16 channels each

* A large backlight LCD to display operation parameters

* 16 sliders for channel, 1 slider for speed/fade control

* 1600 chase steps, 48 chases, up to 99 steps each. Each step contains its speed and cross time, can be set respectively. Trigger mode selectable:Music synchronously and manual speed

* SPEED fade time range is 0.01s-25.5s andCROSS fade time range is 0s-25.5s and the total time amount of current status will be program step time

* 48 scanner scenes can be used directly

* 8 chases.48 scenes operated at the same time.At most 32 scanners can be selected

* The X/Y channels of different scanners can be controlled by modulation wheel

* 16Bit control for absolutely precise movement

* 15 environment programsto output the combination , which are composed of different scenes , chases and manual output quickly

* The music trigger source can be selected between audio line input or inside microphone

* Easy to edit and handle

* The Data auto-saves

* High performance switching power supply, with extremely low power harmonious distortion and wide range of voltage, suit for the requirement of different country simultaneously LED lamp connector

* Power input: AC88-256V 50/60Hz

* Dimension: 498mm × 420mm × 115mm

* Net Weight: 6.3KG


① Running time and Cross time could be changed freely during program running period by moving SPEED & CROSS sliders or run as preset time directly if SPEED & CROSS sliders be put at AUTO position.

② Cross time of all channels mode or X/Y channel only mode could be switch easily during program running period.

③ After assign X/Y wheel, sliders and X/Y wheel could be used to change DMX value of each channel together ( Sliders for fast change and X/Y wheel for fine adjustment).
