1375-B- Signal Switch
- PID：1375-B
- Wechat：13825163720; 18928719131
- Phone: (8620)36399170
- Tel: (8620)36399170
- Email: info@showart.com.cn
- FEEDBACK
Technical Parameter
* DMX 512/1990 Standard
* 2 DMX optical isolated outputs:
OUTPUT 1 ( input 1A & 1B DMX signal) and
OUTPUT 2 ( input 2A & 2B DMX signal)
* BACKUP mode control to ensure the signal is not interrupted
* BACKUP mode: when input 1A DMX- signal fail, input 1B DMX- signal take over immediately. When input 2A DMX- signal fail, input 2B DMX- signal take over immediately
* Independent input and output signal
* Input and output ports use Inrush Protection
* Each DMX output has super driving ability. Each input has LED indicator
* Wide input stable electric power supply, suitable for voltage input of different countries
* Neutrik 3pins XLR
* Voltage: output DC 9V-12V 1A , input AC88～256V 50/60Hz
* Dimension: 176mm X 117mmX 58mm
* Net weight : 0.7kg
Up to CE standard, UL standard and GB 7000.15-2000 standard
