Technical Parameter

* 1 set of DMX512 signal input and play interface,control 512 channels

* Play mode can be adjusted, free choice of Multi, Cycle, Single mode. And AUTO and MUSIC ways can be selected to trigger chase to run

* Each program can adjust play speed freely inautomatic play mode

* Built-in 512M storage, stored in 8 programs, each program can record for more than 5 minutes (depending on the channels of the console and the size of the content)

* Two interface manipulation modes: system (all functions) and user (only play function)

* Microphone pickup, AV audio input, sensitivity can be adjusted

* RJ45 or RS232 connect central control or touch panel

* Support XLR pin 3 / RJ45 network port

* USB disk backup and download

* Power input : AC88~256V 50/60Hz

* Dimension: 482mm×173mm×44mm

* Net Weight: 1.65kg

Up to CE standard, UL standard and GB7000.15-2000 standard
